Overview

TGL Exterior area fixtures come with sleek modern designs, high grade LED chips, unique features such as rotatable heads, adjustable wattages and industry leading driver design that allows our fixtures to operate with voltage ranges of 120-347V. Unique features such as built-in junction boxes, easy access compartments and wide voltage range drivers facilitate quick easy installation and fewer project delays.  Our fixtures are also equipped with THUNDERSHOCKTM protection, advanced heat syncs and aluminum body construction allowing the fixtures to perform in the toughest conditions.   An innovative combination of aesthetics, energy savings, safety and durability that delivers 60% plus in energy savings vs. MH/HPS lighting.

https://www.thinkgreenled.com/wp-content/uploads/2020/09/hexagon-white-small.png
https://www.thinkgreenled.com/wp-content/uploads/2021/01/Exterior1new_sm-e1647298385845-640x600.jpg
https://www.thinkgreenled.com/wp-content/uploads/2021/01/Exterior2sms-e1647298409211-640x600.jpg
https://www.thinkgreenled.com/wp-content/uploads/2020/11/green-hexagon-shape.png
bt_bb_section_bottom_section_coverage_image
Features
  • Wide beam angle lens to reduce glare and provide uniform lighting distribution.
  • Wide voltage Range 120-347V covers all voltage scenarios for Canadian market.
  • ThundershockTM protects luminaire under tough electrical conditions (10,000V).
  • TGL mounting system fits round poles, flat poles, and pole tops for quick installation.
  • Access panels built in mounting arms to make quick connections.
  • Aluminum Body with advanced heat sync for superior thermal management.

Infinity Series Pole Light

The TGL Infinity Series Pole Light fixtures offer sleek modern design with advanced driver that allows our fixtures to operate with voltage range 120-347V.  The wide voltage range and innovative selection of mounts allows for fewer project delays and quick cost-effective installations.  Our fixtures are also equipped with THUNDERSHOCKTM protection allowing the fixture to withstand some of the toughest electrical conditions.  The Infinity Series pole Light lasts up to 3 times longer than MH/HPS lighting and delivers 60% or more in electricity savings while delivering great lighting.

Infinity Series Pole Lights - 1
Infinity Series Pole Lights - 3
  • Click to View
  • Specifications
  • Documents
  • Videos
Type Model Number Voltage Watts Lumens Colour Temp Beam Angle CRI Rated Life
Pole Light TGL-INF-100WXY-50K 120-347V 100W 13,523 5000K 160 x 96 >70 50000
Pole Light TGL-INF-150WXY-50K 120-347V 150W 20,377 5000K 160 x 96 >70 50000
Pole Light TGL-INF-240WXY-50K 120-347V 240W 33,565 5000K 125 x 160 >70 50000
Pole Light TGL-INF-300WXY-50K 120-347V 300W 41,669 5000K 125 x 160 >70 50000
Type Model Number Data Sheets IES Files Install Instructions Brochure
Pole Light TGL-INF-100WXY-50K View View View View
Pole Light TGL-INF-150WXY-50K View View
Pole Light TGL-INF-240WXY-50K View View
Pole Light TGL-INF-300WXY-50K View View

No videos

Features
  • Wide voltage Range 120-347V covers all voltage scenarios for Canadian market.
  • ThundershockTM protects luminaire under tough electrical conditions (10,000V).
  • Glass Semi-Cut Off Lens for uniform lighting and reduced glare.
  • Multiple knockouts built in junction box to facilitate quick and easy installations.
  • Aluminum Body for superior thermal management.

Infinity Series Wall Pack (Semi-Cut off)

The TGL Infinity Series wall pack comes with traditional design and semi cut-off lens to guide light downwards to control lighting spread.  The fixture also features a driver that allows voltage range 120-347V and a design that allows connections within the fixtures to facilitate quick and easy installations.  This fixture is also equipped with THUNDERSHOCKTM protection allowing the wall pack to operate in some of the toughest electrical conditions.  The Infinity Series wall pack lasts up to 3 times longer than MH/HPS lighting while delivering 60% or more in electricity savings while delivering great lighting.

Infinity WP - 1
Infinity WP - 4
  • Click to View
  • Specifications
  • Documents
  • Videos
Type Model Number Voltage Watts Lumens Colour Temp Beam Angle CRI Rated Life
Wall Pack Semi Cut Off TGL-INFREG-40WX 120-347V 40W 5,549 5000K 110 80 50000
Wall Pack Semi Cut Off TGL-INFREG-60WX 120-347V 60W 8,339 5000K 110 80 50000
Wall Pack Semi Cut Off TGL-INFREG-80WX 120-347V 80W 10,853 5000K 110 80 50000
Wall Pack Semi Cut Off TGL-INFREG-100WX 120-347V 100W 13,297 5000K 110 80 50000
Type Model Number Data Sheets IES Files Install Instructions Brochure
Wall Pack Semi Cut Off TGL-INFREG-40WX View View View View
Wall Pack Semi Cut Off TGL-INFREG-60WX View View
Wall Pack Semi Cut Off TGL-INFREG-80WX View View
Wall Pack Semi Cut Off TGL-INFREG-100WX View View

No videos

Features
  • Beautiful Streamlined Modern Design
  • 1-2 Rotatable heads to customize light spread (up/down).
  • Oversized Heat Sync and ventilation for superior thermal management.
  • Multiple knockouts built in junction box to facilitate quick and easy installations.
  • Wide voltage Range 120-347V covers all voltage scenarios for Canadian market.
  • ThundershockTM protects luminaire under tough electrical conditions (10,000V).

Apollo Wall Pack (Rotatable)

The TGL Apollo Wall Pack combines streamlined modern design with advanced functionality to create the industries most innovative wall pack.  The Apollo features 1 or 2 heads that can rotate 60 – 270 degrees to give you the ability to customize your lighting spread (up-light or downlight).  It also features a built-in junction box, our 120-347V driver technology, and ThundershockTM high voltage protection.  Great for creating a modern distinctive look while delivering unique lighting designs and maximum energy savings.

Apollo WP - 1
Apollo WP - 3
Apollo WP - 4
Apollo WP - 6
  • Click to View
  • Specifications
  • Documents
  • Videos
Type Model Number Voltage Watts Lumens Colour Temp Beam Angle CRI Rated Life
Wall Pack Full Cut off TGL-ROT-40WX 120-347V 40W 5,549 5000K 110 80 50000
Wall Pack Full Cut off TGL-ROT-60WX 120-347V 60W 8,339 5000K 110 80 50000
Wall Pack Full Cut off TGL-ROT-80WX 120-347V 80W 10,853 5000K 110 80 50000
Type Model Number Data Sheets IES Files Install Instructions Brochure
Wall Pack Full Cut off TGL-ROT-40WX View View View View
Wall Pack Full Cut off TGL-ROT-60WX View View
Wall Pack Full Cut off TGL-ROT-80WX View View

No videos

Features
  • Traditional Wall pack Design to provide great light spread
  • High grade glass lens to maximize light spread and reduce glare.
  • Wide voltage Range 120-347V covers all voltage scenarios for Canadian market.
  • ThundershockTM protects luminaire under tough electrical conditions (10,000V).
  • Multiple knockouts built in junction box to facilitate quick and easy installations.

Ultra Wall Pack (Adjustable Wattage)

The Ultra Walpack comes with a traditional design, industry leading LED Chip Set, high grade glass lens and our ThundershockTM high voltage protection for commercial grade performance.  It also features our 120-347V driver and built-in junction box to facilitate fast easy installations.  What separates the Ultra Wall Pack is the unique ability to change between 3 wattages and lighting output settings 40W – 5,549 Lumens, 60W – 8,339 Lumens, and 80W – 10,853 Lumens giving you the ability to increase or decrease lighting levels and energy savings.

Wallpack WA & CCT - 4
Wallpack WA & CCT - 6
  • Click to View
  • Specifications
  • Documents
  • Videos
Type Model Number Voltage Watts Lumens Colour Temp Beam Angle CRI Rated Life
Wall Pack Regular TGL-UWP-40WX 120-347V 40W 5,549 5000K 110 80 50000
Wall Pack Regular TGL-UWP-60WX 120-347V 60W 8,339 5000K 110 80 50000
Wall Pack Regular TGL-UWP-80WX 120-347V 80W 10,853 5000K 110 80 50000
Wall Pack Regular TGL-UWP-100WX 120-347V 100W 13,297 5000K 110 80 50000
Type Model Number Data Sheets IES Files Install Instructions Brochure
Wall Pack Regular TGL-UWP-40WX View View View View
Wall Pack Regular TGL-UWP-60WX View View
Wall Pack Regular TGL-UWP-80WX View View
Wall Pack Regular TGL-UWP-100WX X X

No videos

Features
  • Wide voltage Range 120-347V covers all voltage scenarios for Canadian market.
  • ThundershockTM protects luminaire under tough electrical conditions (4,000V).
  • Frosted lens for uniform lighting and reduced glare.
  • Shatterproof Polycarbonate lens.
  • Aluminum Body for superior thermal management.
  • Water Resistant (IP65 rating).

Infinity Series Corn Bulbs (Ballast Bypass)

The TGL Infinity Series corn bulbs are designed to replace 70-250W MH/HPS/HID lamps.  Lasting up to 3 times longer than MH/HPS/HID lighting and with more than 76% energy savings, it is the perfect solution for retrofit of decorative lamp post, sconces, and recessed canopy lights for commercial exterior lighting projects.  TGL infinity series LED corn bulbs come with leading edge features such as an internal driver with voltage range of 120-347V and, THUNDERSHOCK™ to protect against tough electrical conditions.

27W Corn Bulb
Infinity Corn Bulbs 27W - 1
Infinity Corn Bulbs 27W - 2
54W Corn Bulb
Infinity Corn Bulbs 54W - 6
Infinity Corn Bulbs 54W - 4
  • Click to View
  • Specifications
  • Documents
  • Videos
Type Model Number Voltage Watts Lumens Colour Temp Beam Angle CRI Rated Life
Corn Bulb E26 TGL-UCB-027WEC 120-347V 27W 3054 5000K 360 80 50000
Corn Bulb E26 TGL-UCB-054WEC 120-347V 54W 6122 5000K 360 80 50000
Type Model Number Data Sheet IES Files Install Instructions Brochure
Corn Bulb E26 TGL-UCB-027WEC View View View View
Corn Bulb E26 TGL-UCB-054WEC View View

No videos
