Overview

The TGL Universal Downlight combines innovative modular design with high grade full aluminum construction to provide great thermal management and a distinguished high-grade finish to complement any interior design.  The innovative modular design allows for a wide variety of interchangeable round and square aluminum trims to our lighting engine.  The fixture also incorporates advanced features such as, our leading-edge driver that handles 120 to 347V, built in junction box, options for changing colour temperature, and options to adjust light output and wattage to allow for great flexibility to facilitate rapid project execution.

https://www.thinkgreenled.com/wp-content/uploads/2020/09/hexagon-white-small.png
https://www.thinkgreenled.com/wp-content/uploads/2021/01/LED-Mod-Square-Downlights1-640x600.jpg
https://www.thinkgreenled.com/wp-content/uploads/2021/01/LED-Mod-Square-Downlights3-640x600.jpg
https://www.thinkgreenled.com/wp-content/uploads/2020/11/green-hexagon-shape.png
bt_bb_section_bottom_section_coverage_image
led-downlight-combination
Features
  • Modular Design allows for multiple aluminum trims and light sources.
  • Aluminum body construction for elegant aesthetics and great thermal management.
  • Leading edge driver with 120-347V range to handle all electrical conditions.
  • Built in junction box to facilitate quick easy installation.

The TGL Universal Downlight (Base Model)

Our TGL Universal Downlight base model comes with a modular design allowing for various combinations of light engines and aluminum trims and single colour temperature, single wattage.

Universal DL Base1
Universal DL Base2
  • Click to View
  • Specifications
  • Documents
  • Videos
TypeModel NumberVoltageWattsLumensColour TempBeam AngleCRIDimmable
0-10V
Rated Life
Downlight 4”TGL-PREM4DL-10W120-347V10W7504000K12080Yes50000
Downlight 6”TGL-PREM6DL-10W120-347V10W7504000K12080Yes50000
Downlight 8”TGL-PREM8DL-10W120-347V10W7504000K12080Yes50000
Downlight 10”TGL-PREM10DL-10W120-347V10W7504000K12080Yes50000
Downlight 4”TGL-PREM4DL-15W120-347V15W12604000K12080Yes50000
Downlight 6”TGL-PREM6DL-15W120-347V15W12604000K12080Yes50000
Downlight 8”TGL-PREM8DL-15W120-347V15W12604000K12080Yes50000
Downlight 10”TGL-PREM10DL-15W120-347V15W12604000K12080Yes50000
Downlight 4”TGL-PREM4DL-20W120-347V20W17204000K12080Yes50000
Downlight 6”TGL-PREM6DL-20W120-347V20W17204000K12080Yes50000
Downlight 8”TGL-PREM8DL-20W120-347V20W17204000K12080Yes50000
Downlight 10”TGL-PREM10DL-20W120-347V20W17204000K12080Yes50000
TypeModel NumberData SheetsIES Files Install InstructionsBrochures
Downlight 4”TGL-PREM4DL-10WViewXViewTGL Phantom Series Universal Downlight

TGL Universal Downlight LED Disk

Downlight 6”TGL-PREM6DL-10WViewX
Downlight 8”TGL-PREM8DL-10WViewX
Downlight 10”TGL-PREM10DL-10WViewX
Downlight 4”TGL-PREM4DL-15WViewX
Downlight 6”TGL-PREM6DL-15WViewX
Downlight 8”TGL-PREM8DL-15WViewX
Downlight 10”TGL-PREM10DL-15WViewX
Downlight 4”TGL-PREM4DL-20WViewX
Downlight 6”TGL-PREM6DL-20WViewX
Downlight 8”TGL-PREM8DL-20WViewX
Downlight 10”TGL-PREM10DL-20WViewX

No videos

Features
  • Modular Design allows for multiple aluminum trims and light sources.
  • Aluminum body construction for elegant aesthetics and great thermal management.
  • Leading edge driver with 120-347V range to handle all electrical conditions.
  • Built in junction box to facilitate quick easy installation.
  • Ability to change between 3 colour temperatures (2700K, 3000K, 3500K).

The TGL Universal CCT Tunable Downlight (2700K, 3000K, 3500K)

The TGL Universal Downlight CCT Tunable version combines our base model with a switch which gives you the ability to change between 3 colour temperatures (2700K, 3000K, 3500K) allowing for greater flexibility in choice of colour temperature.

Universal DL 3CCT1
Universal DL 3CCT2
  • Click to View
  • Specifications
  • Documents
  • Videos
TypeModel NumberVoltageWattsLumensColour TempBeam AngleCRIDimmable
0-10V
Rated Life
Downlight 4”TGL-PREM4DL-10W-XXE120-347V10W750Tunable12080Yes50000
Downlight 6”TGL-PREM6DL-10W-XXE120-347V10W750Tunable12080Yes50000
Downlight 8”TGL-PREM8DL-10W-XXE120-347V10W750Tunable12080Yes50000
Downlight 10”TGL-PREM10DL-10W-XXE120-347V10W750Tunable12080Yes50000
Downlight 4”TGL-PREM4DL-20W-XXE120-347V20W1720Tunable12080Yes50000
Downlight 6”TGL-PREM6DL-20W-XXE120-347V20W1720Tunable12080Yes50000
Downlight 8”TGL-PREM8DL-20W-XXE120-347V20W1720Tunable12080Yes50000
Downlight 10”TGL-PREM10DL-20W-XXE120-347V20W1720Tunable12080Yes50000
TypeModel NumberData SheetsIES Files Install InstructionsBrochures
Downlight 4”TGL-PREM4DL-10W-XXEViewXViewTGL Phantom Series Universal Downlight

TGL Universal Downlight LED Disk

Downlight 6”TGL-PREM6DL-10W-XXEViewX
Downlight 8”TGL-PREM8DL-10W-XXEViewX
Downlight 10”TGL-PREM10DL-10W-XXEViewX
Downlight 4”TGL-PREM4DL-20W-XXEViewX
Downlight 6”TGL-PREM6DL-20W-XXEViewX
Downlight 8”TGL-PREM8DL-20W-XXEViewX
Downlight 10”TGL-PREM10DL-20W-XXEViewX

No videos

Features
  • Modular Design allows for multiple aluminum trims and light sources.
  • Aluminum body construction for elegant aesthetics and great thermal management.
  • Leading edge driver with 120-347V range to handle all electrical.
  • Built in junction box to facilitate quick easy installation.
  • Power adjustable between 3 wattages (27W, 34W, 40W).
  • Color Temperature adjustable (3000K, 3500K, 4000K).

The TGL Universal Downlight CCT and Power Adjustable Downlight

This TGL Universal Downlight is equipped with switches which allow the user to adjust CCT and Power on the job sites. Select between color temperatures of (3000K, 3500K and 4000K) and wattages options of 27W – 2430 Lumens, 34W – 2890 Lumens and 40W – 3200 Lumens. This gives you the ability to quickly increase or decrease light levels and power consumption / energy savings plus adjust colour temperature of the fixture.

Universal DL WA1
Universal DL WA2
  • Click to View
  • Specifications
  • Documents
  • Videos

Rated Life

TypeModel NumberVoltageWattsLumensColour TempBeam AngleCRIDimmable 0-10VRated Life
Downlight 4”TGL-PREM4DL-27W120-347V27W24303000, 3500, 400012080Yes50000
Downlight 6”TGL-PREM6DL-27W120-347V27W24303000, 3500, 400012080Yes50000
Downlight 8”TGL-PREM8DL-27W120-347V27W24303000, 3500, 400012080Yes50000
Downlight 10”TGL-PREM10DL-27W120-347V27W24303000, 3500, 400012080Yes50000
Downlight 4”TGL-PREM4DL-34W120-347V34W28903000, 3500, 400012080Yes50000
Downlight 6”TGL-PREM6DL-34W120-347V34W28903000, 3500, 400012080Yes50000
Downlight 8”TGL-PREM8DL-34W120-347V34W28903000, 3500, 400012080Yes50000
Downlight 10”TGL-PREM10DL-34W120-347V34W28903000, 3500, 400012080Yes50000
Downlight 4”TGL-PREM4DL-40W120-347V40W32003000, 3500, 400012080Yes50000
Downlight 6”TGL-PREM6DL-40W120-347V40W32003000, 3500, 400012080Yes50000
Downlight 8”TGL-PREM8DL-40W120-347V40W32003000, 3500, 400012080Yes50000
Downlight 10”TGL-PREM10DL-40W120-347V40W32003000, 3500, 400012080Yes50000
TypeModel NumberData SheetsIES Files Install InstructionsBrochures
Downlight 4”TGL-PREM4DL-27WViewXViewTGL Phantom Series Universal Downlight

TGL Universal Downlight LED Disk

Downlight 6”TGL-PREM6DL-27WViewX
Downlight 8”TGL-PREM8DL-27WViewX
Downlight 10”TGL-PREM10DL-27WViewX
Downlight 4”TGL-PREM4DL-34WViewX
Downlight 6”TGL-PREM6DL-34WViewX
Downlight 8”TGL-PREM8DL-34WViewX
Downlight 10”TGL-PREM10DL-34WViewX
Downlight 4”TGL-PREM4DL-40WViewX
Downlight 6”TGL-PREM6DL-40WViewX
Downlight 8”TGL-PREM8DL-40WViewX
Downlight 10”TGL-PREM10DL-40WViewX
