High Performance
LED Tubes

bt_bb_section_bottom_section_coverage_image

TGL High Performance LED Tubes

Using next generation technologies TGL led tubes Maximize Energy Savings, provides Unmatched life, offers Unique functionality, with advanced safety features.  Save over 63% vs T8 fluorescent with paybacks under 1yr.

https://www.thinkgreenled.com/wp-content/uploads/2020/09/hexagon-white-small.png
https://www.thinkgreenled.com/wp-content/uploads/2021/01/Office-1-640x600.jpg
https://www.thinkgreenled.com/wp-content/uploads/2021/01/Office-2-640x600.jpg
https://www.thinkgreenled.com/wp-content/uploads/2020/11/green-hexagon-shape.png
bt_bb_section_bottom_section_coverage_image
Features
  • Plug & Play works with existing fixtures (Instant start T8 ballast required).
  • Industrial grade construction with ability to absorb heavy direct impact.
  • Driverless design & Thermal management easily handles voltage spikes (1000V+).
  • High Efficiency at 9.5W bare lamp consumption and 1800 lumens.
  • Proven reliability and energy efficiency.

Premium T8 LED Tubes (Type A)

Perhaps our industries most energy efficient LED tube the TGL Premium T8 features industry leading high efficiency chips combined with a driverless circuit design to deliver maximum energy efficiency and Unmatched Life.  Using high grade construction material such as fireproof PCB and aluminum the Premium tube is capable of withstanding high heat, heavy direct impact and offers advanced thermal protection ThunderShockTM which allows it to easily withstand voltage spikes over 1,000V.  A valuable combination of energy efficiency and durability that results in huge energy and maintenance cost savings in the long run.

Our premium T8 also has AC-DirectTM so no electrical wiring is required, it works with your existing T8 Fluorescent fixtures 120-347V fixtures (High Compatibility Plug & Play) making for quick easy cost-effective installations.

TGL Prem T8
Driverless Design
  • Click to View
  • Specifications
  • Documents
  • Videos
Type Model Number Voltage Watts Lumens Colour Temp Beam Angle CRI Rated Life
4FT PREM-12W-4FT-500K 120-347V 11W 1800 5000K 120 80 50000
4FT PREM-12W-4FT-410K 120-347V 11W 1800 4100K 120 80 50000
4FT PREM-12W-4FT-350K 120-347V 11W 1750 3500K 120 80 50000
3FT TGL-14W-3FT-500K 120-347V 12W 1600 5000K 120 80 50000
3FT TGL-14W-3FT-410K 120-347V 12W 1550 4100K 120 80 50000
3FT TGL-14W-3FT-350K 120-347V 12W 1500 3500K 120 80 50000
2FT TGL-9W-2FT-500K 120-347V 7.9W 990 5000K 120 80 50000
2FT TGL-9W-2FT-410K 120-347V 7.9W 850 4100K 120 80 50000
2FT TGL-9W-2FT-350K 120-347V 7.9W 770 3500K 120 80 50000
Type Model Number Data Sheets Installation Instructions Ballast Compatibility List Brochure
4FT PREM-12W-4FT-500K View View View View
4FT PREM-12W-4FT-410K
4FT PREM-12W-4FT-350K
3FT TGL-14W-3FT-500K View
3FT TGL-14W-3FT-410K
3FT TGL-14W-3FT-350K
2FT TGL-9W-2FT-500K View
2FT TGL-9W-2FT-410K
2FT TGL-9W-2FT-350K

No videos

Features
  • Dimmable works with select existing T8 dimmable ballasts.
  • Plug & Play dimmable tube (see ballast compatibility list).
  • Thermal fuse to protect against electrical arc & overheating.
  • Fire Proof construction with metallic endcaps and glass.
  • High Performance at 10.5W bare lamp consumption.

Vintage T8 LED Tubes (Dimmable Type A)

The TGL Vintage T8 LED tube is one of the industries first dimmable direct replacement LED tubes and works directly with select T8 dimmable ballasts with no electrical wiring needed. The vintage tube also comes with advanced safety features like thermal protection safety fuse and fireproof construction consisting of frosted glass and metallic end caps to protect against electrical arcs and power surges hence making it one of the industries safest led tubes.

Our vintage series also has AC-DirectTM so no electrical wiring is required, it works with your existing Fluorescent fixtures 120-347V fixtures (High Compatibility Plug & Play) making for quick easy cost-effective installations.

Vintage T8 Tubes - 3
Dimmable Direct Replacement
  • Click to View
  • Specifications
  • Documents
  • Videos
Type Model Number Voltage Watts Lumens Colour Temp Beam Angle CRI Dimmable Rated Life
4FT TGL-Vin-15W-850-7 120-347V 15W 2200 5000K 320 83 Yes 50000
4FT TGL-Vin-15W-840-7 120-347V 15W 2200 4000K 320 83 Yes 50000
4FT TGL-Vin-15W-835-7 120-347V 15W 2100 3500K 320 83 Yes 50000
4FT TGL-Vin-10.5W-850-1 120-347V 10.5W 1800 5000K 320 83 Yes 50000
4FT TGL-Vin-10.5W-840-1 120-347V 10.5W 1750 4000K 320 83 Yes 50000
4FT TGL-Vin-10.5W-835-1 120-347V 10.5W 1700 3500K 320 83 Yes 50000
3FT TGL-Vin3FT-11W-850-9 120-347V 11W 1650 5000K 320 83 Yes 50000
3FT TGL-Vin3FT-11W-840-9 120-347V 11W 1625 4000K 320 83 Yes 50000
3FT TGL-Vin3FT-11W-835-9 120-347V 11W 1600 3500K 320 83 Yes 50000
2FT TGL-Vin2FT-8W-850-1 120-347V 8W 1300 5000K 320 83 Yes 50000
2FT TGL-Vin2FT-8W-840-1 120-347V 8W 1300 4000K 320 83 Yes 50000
2FT TGL-Vin2FT-8W-835-1 120-347V 8W 1250 3500K 320 83 Yes 50000
Type Model Number Data Sheets Installation Instructions Ballast Compatibility List Brochure
4FT TGL-Vin-15W-850-7 View View View View
4FT TGL-Vin-15W-840-7
4FT TGL-Vin-15W-835-7
4FT TGL-Vin-10.5W-850-1 View
4FT TGL-Vin-10.5W-840-1
4FT TGL-Vin-10.5W-835-1
3FT TGL-Vin3FT-11W-850-9 View
3FT TGL-Vin3FT-11W-840-9
3FT TGL-Vin3FT-11W-835-9
2FT TGL-Vin2FT-8W-850-1 View
2FT TGL-Vin2FT-8W-840-1
2FT TGL-Vin2FT-8W-835-1

No videos

Features
  • High Efficiency 9.8W system power consumption
  • Single or Double ended power compatible with shunted and non-shunted lamp holders

Advanced Safety Features

Safety Switch

  • Provides safety to installers by cutting power until both ends of tube are engaged.

Unintended Use Protection

  • If the tube is installed into a fixture with a ballast it safely powers down.

ThundershockTM

  • If tube overheats it powers off, then resumes function once cool.

Fireproof Construction

  • Frosted glass and fireproof PC end caps.

T8 Xcal LED Tube (Type B – Bypass Tube)

TGL Xcal LED Tube are designed to operate with 120-347V direct line voltage (bypass), it does not require a fluorescent ballast to work. This provides the advantage of eliminating future maintenance costs of replacing ballasts and improved efficiency as power consumption from ballast is eliminated.  In addition to enhanced energy and maintenance cost savings our bypass tubes have advanced safety features to protect against electrical shock and unintended use.

TGL T8 Bypass1
Ballast Bypass Tube
  • Click to View
  • Specifications
  • Documents
  • Videos
Type Model Number Voltage Watts Lumens Colour Temp Beam Angle CRI Dimmable Rated Life
4FT TGL-VBP4FT-15W-850 120-347V 15W 2200 5000K 330 83 No 50000
4FT TGL-VBP4FT-15W-840 120-347V 15W 2200 4000K 330 83 No 50000
4FT TGL-VBP4FT-15W-350 120-347V 15W 2200 3500K 330 83 No 50000
4FT TGL-VBP4FT-9.8W-850 120-347V 9.8W 1700 5000K 330 83 No 50000
4FT TGL-VBP4FT-9.8W-840 120-347V 9.8W 1700 4000K 330 83 No 50000
4FT TGL-VBP4FT-9.8W-835 120-347V 9.8W 1700 3500K 330 83 No 50000
3FT TGL-VBP3FT-12W-850 120-347V 12W 1600 5000K 330 83 No 50000
3FT TGL-VBP3FT-12W-840 120-347V 12W 1600 4000K 330 83 No 50000
3FT TGL-VBP3FT-12W-835 120-347V 12W 1600 3500K 330 83 No 50000
2FT TGL-VBP2FT-7W-850 120-347V 7W 950 5000K 330 83 No 50000
2FT TGL-VBP2FT-7W-840 120-347V 7W 950 4000K 330 83 No 50000
2FT TGL-VBP2FT-7W-835 120-347V 7W 950 3500K 330 83 No 50000
Type Model Number Data Sheets Installation Instructions Brochure
4FT TGL-VBP4FT-15W-850 View View View
4FT TGL-VBP4FT-15W-840
4FT TGL-VBP4FT-15W-350
4FT TGL-VBP4FT-9.8W-850 View
4FT TGL-VBP4FT-9.8W-840
4FT TGL-VBP4FT-9.8W-835
3FT TGL-VBP3FT-12W-850 View
3FT TGL-VBP3FT-12W-840
3FT TGL-VBP3FT-12W-835
2FT TGL-VBP2FT-7W-850 View
2FT TGL-VBP2FT-7W-840
2FT TGL-VBP2FT-7W-835

No videos

Features
  • Dimmable works with select existing T5 dimmable ballasts.
  • Plug & Play dimmable tube (see ballast compatibility list).
  • Thermal fuse to protect against electrical arc & overheating.
  • Fire Proof construction with metallic endcaps and glass.

Vintage T5 LED Tubes (Dimmable - Type A)

The Vintage T5 LED tube is one of our industries only dimmable direct replacement T5 LED tubes.  This tube works directly with your existing T5 fixture and ballast (No electrical wiring needed) making for quick easy installation.  The vintage tube also comes with advanced safety features like thermal protection safety fuse and fireproof construction consisting of frosted glass and metallic end caps to protect against electrical arcs and power surges hence making it one of the industries safest led tubes.

T5 Vintage 2
Dimmable Plug & Play
Vintage T5HE LED Tubes (28W T5 Replacement)
  • Click to View
  • Specifications
  • Documents
  • Videos
Type Model Number Voltage Watts Lumens Colour Temp Beam Angle CRI Dimmable Rated Life
4FT Vin-T5HE4FT-13-5000K 120-347V 13W 2000 5000K 320 83 Yes 50000
4FT Vin-T5HE4FT-13-4000K 120-347V 13W 2000 4000K 320 83 Yes 50000
4FT Vin-T5HE4FT-13-3500K 120-347V 13W 1900 3500K 320 83 Yes 50000
4FT Vin-T5HE4FT-13-3000K 120-347V 13W 1900 3000K 320 83 Yes 50000
3FT Vin-T5HE3FT-9-5000K 120-347V 9W 1300 5000K 320 83 Yes 50000
3FT Vin-T5HE3FT-9-4000K 120-347V 9W 1250 4000K 320 83 Yes 50000
3FT Vin-T5HE3FT-9-3500K 120-347V 9W 1200 3500K 320 83 Yes 50000
3FT Vin-T5HE3FT-9-3000K 120-347V 9W 1200 3000K 320 83 Yes 50000
2FT Vin-T5HE2FT-6-5000K 120-347V 6W 1000 5000K 320 83 Yes 50000
2FT Vin-T5HE2FT-6-4000K 120-347V 6W 950 4000K 320 83 Yes 50000
2FT Vin-T5HE2FT-6-3500K 120-347V 6W 900 3500K 320 83 Yes 50000
2FT Vin-T5HE2FT-6-3000K 120-347V 6W 900 3000K 320 83 Yes 50000
Type Model Number Data Sheets Ballast Compatibility List Installation Instructions Brochure
4FT Vin-T5HE4FT-13-5000K View View View View
4FT Vin-T5HE4FT-13-4000K
4FT Vin-T5HE4FT-13-3500K
4FT Vin-T5HE4FT-13-3000K
3FT Vin-T5HE3FT-9-5000K View
3FT Vin-T5HE3FT-9-4000K
3FT Vin-T5HE3FT-9-3500K
3FT Vin-T5HE3FT-9-3000K
2FT Vin-T5HE2FT-6-5000K View
2FT Vin-T5HE2FT-6-4000K
2FT Vin-T5HE2FT-6-3500K
2FT Vin-T5HE2FT-6-3000K

No videos

Vintage T5HO LED Tubes (54W T5HO Fluorescent)
  • Click to View
  • Specifications
  • Documents
  • Videos
Type Model Number Voltage Watts Lumens Colour Temp Beam Angle CRI Dimmable Rated Life
4FT Vin-T5HO4FT-25.5-5000K 120-347V 25.5W 3300 5000K 320 83 Yes 50000
4FT Vin-T5HO4FT-25.5-4000K 120-347V 25.5W 3300 4000K 320 83 Yes 50000
4FT Vin-T5HO4FT-25.5-3500K 120-347V 25.5W 3200 3500K 320 83 Yes 50000
4FT Vin-T5HO4FT-25.5-3000K 120-347V 25.5W 3200 3000K 320 83 Yes 50000
Type Model Number Data Sheets Ballast Compatibility List Installation Instructions Brochure
4FT Vin-T5HO4FT-25.5-5000K View View View View
4FT Vin-T5HO4FT-25.5-4000K
4FT Vin-T5HO4FT-25.5-3500K
4FT Vin-T5HO4FT-25.5-3000K

No videos
